Product model	EMT3
Cargo box Volume	1.2m³
Rated load capacity	3000kg
Unloading height	2350mm
oading height	1250mm
Ground clearance	≥240mm
Turning radius	≤4900mm
Climbing ability (heavy load)	≤6°
Maximum lift angle of the cargo box	45±2°
Wheel track	1380mm
Tire model	Front tire 600-14/rear tire 700-16(wire tire)
shock absorption system	Front: Damping Three shock absorber Rear: 13 thickened leaf springs
Operation   system	Medium plate(rack and pinion type)
Control  system	Intelligent controller
Lighting system	Front and rear LED lights
Maximum   Speed	25km/h
Motor   model/power,	AC  10KW
No.Battery	12 pieces, 6V,200Ah maintenance-free
Voltage	72V
Overall dimension	ength3700mm*width         1380mm*height1250mm
Cargo  box  dimension(outer  diameter  )	Length    2200mm*width    1380mm*height450mm
Cargo box plate thickness	3mm
Frame	Rectangular tube welding
Overall weight	1320kg

1. What are the main models and specifications of your mining dump trucks? Our company produces various models and specifications of mining dump trucks, including large, medium, and small-sized ones. Each model has different loading capacities and dimensions to meet various mining requirements. 2. Does your mining dump truck have safety features? Yes, we place a high emphasis on safety. Our mining dump trucks are equipped with advanced safety features, including brake assistance, anti-lock braking system (ABS), stability control system, etc., to minimize the risk of accidents during operation. 3. How can I place an order for your mining dump trucks? Thank you for your interest in our products! You can get in touch with us through the contact information provided on our official website or by calling our customer service hotline. Our sales team will provide detailed product information and assist you in completing your order. 4. Are your mining dump trucks customizable? Yes, we can offer customization services based on specific customer requirements. If you have special requests, such as different loading capacities, configurations, or other customization needs, we will do our best to meet your requirements and provide the most suitable solution.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.The front tire is 600-14, and the rear tire is 700-16, both of which are wire tires, providing excellent traction and durability in mining conditions. The truck is equipped with a damping three shock absorber system in the front and 13 thickened leaf springs at the rear, ensuring a smooth and stable ride even over rough terrain.For operation, it features a medium plate (rack and pinion type) and an intelligent controller for precise control during operations. The lighting system includes front and rear LED lights, ensuring visibility in low-light conditions.The turning radius of the EMT3 is less than or equal to 4900mm, providing it with good maneuverability even in confined spaces. The wheel track is 1380mm, and it has a climbing ability of up to 6° when carrying a heavy load. The cargo box can be lifted to a maximum angle of 45±2°, enabling efficient unloading of materials.The EMT3 is powered by an AC 10KW motor, which is driven by twelve maintenance-free 6V, 200Ah batteries, providing a voltage of 72V. This powerful electric setup allows the truck to reach a maximum speed of 25km/h, ensuring efficient transportation of materials within mining sites. The overall dimensions of the EMT3 are: Length 3700mm, Width 1380mm, Height 1250mm. The cargo box dimensions (outer diameter) are: Length 2200mm, Width 1380mm, Height 450mm, with a cargo box plate thickness of 3mm. The truck's frame is constructed using rectangular tube welding, ensuring a sturdy and robust structure.The overall weight of the EMT3 is 1320kg, and with its high load capacity and reliable design, it is an excellent choice for various mining applications, offering efficient and dependable material transportation solutions.
