project		Main technical parameters
model		UPC
curb weight (kg)		4840
Brake type		Broken gas brake
Minimum pass capacity radius(mm)		Lateral 8150, medial 6950
wheel  base  (mm)		3000mm
tread  (mm)		Front pitch 1550 / rear pitch 1545
Minimum   ground   clearance(mm)		220
Overall dimensions  (length,width and height)		6210×2080×1980±200mm
Outside size of the carriage		4300×1880×1400mm
maximum  gradability(%)		25%/   14*
Fuel tank capacity (L)		72L
Drive way		Four-wheel drive
Explosion-proof   dieselengine	model	HL4102DZDFB(State  III)
	Explosion-proof diesel engine power	70KW
	power box	Explosion-proof power box

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.Explosion-Proof Diesel Engine The UPC is powered by an explosion-proof diesel engine, model HL4102DZDFB, with a power output of 70KW. This engine is designed to meet State III emission standards, making it environmentally friendly and safe for various operating environments.Product Space With an overall dimension of 6210mm in length, 2080mm in width, and 1980mm in height, the UPC provides ample space for passengers and cargo. The carriage has dimensions of 4300mm in length, 1880mm in width, and 1400mm in height.The vehicle has a minimum pass capacity radius of 8150mm laterally and 6950mm medially, enabling it to maneuver through tight spaces with ease. The four-wheel-drive system allows for enhanced traction and mobility on challenging terrains.Security The vehicle's maximum gradability is 25% under normal conditions, and it has a reduced gradability of 14% in explosion-proof mode, providing excellent performance in both scenarios. The 72L fuel tank capacity ensures long operation without frequent refueling.To ensure safety in hazardous environments, the UPC is equipped with an explosion-proof power box, offering reliable power supply while adhering to safety standards. Overall, the UPC is a robust and reliable people-carrier vehicle suitable for various industrial and commercial applications.
